Main Features:
★ High desalination rate
★ High boron rejection
★ High recovery rate
★ Stable and long service life
★ Strict production & packaging inspection
Product Parameter
|
Model |
Salt Rejection % |
Boron Rejection % |
Product Flow Rate gpd (m3/d) |
Membrane Area ft2 (m2) |
Feed spacer thickness (mil) |
|
ME-8040SW |
99.6 |
93 |
6,700 (25.5) |
400 (37) |
34 |
Test Conditions:
Feed water pressure 800 psi (5.52 MPa);
Feed water temperature 77 °F (25°C);
Feed water concentration 32,000 mg/L as NaCl; 5mg/L boron（pH=8)
Recovery rate 8%;
Feed water pH 7
Minimum Salt Rejection 99.3％
Operating Limits
Maximum operating pressure····················································································1200psi (8.3MPa)
Maximum fee water temperature···············································································113°F (45°C)
Maximum feed water SDI···························································································5
Feed water chlorine concentration ppm····································································Not detected
Continuous operation Feed water pH range ·····························································2–11
Chemical cleaning Feed water pH range ··································································1–12
Maximum pressure drop per element ·······································································15psi (0.10 MPa)
Maximum pressure drop per vessel···········································································50psi (0.34 MPa)
