INTRODUCTION
BOKA Water ULP aromatic polyamide composite membrane elements are specially developed for groundwater and surface water treatment applications. Operating at approximately two-thirds of the pressure required by conventional low-pressure brackish water membranes, they help reduce energy consumption while delivering a salt rejection rate of up to 99.5%. With excellent desalination performance, the membranes can maintain the required permeate flow even under very low operating pressure conditions.
It mainly applies to treatment for surface water, groundwater, municipal water, etc. within salinity<2000mg/L. The application fields include bottled drinking water, dual water supply in residential area or industrial park, food and beverage production, etc. It has the characteristics of higher permeate flow, low operating pressure as well as high rejection rate.
SPECIFICATIONS & PARAMETERS
| Model | Active Area ft 2 (m2) |
Concentrate Channel Spacer mil |
Permeate Flow Rate GPD(m 3 /d) |
Stabilized Salt Rejection (%) |
Minimum Salt Rejection (%) |
| ULP-8040HF | 440(40.9) | 28 | 12500(47.3) | 99.50 | 99.40 |
TEST CONDITION
Standard Test Conditions:
| Solution | Temperature (°C) | pH | Operating Pressure psi(MPa) |
Recovery (%) |
| 1500mg/L NaCl | 25 | 7.5-8.0 | 150(1.03) | 15 |
Water Production Fluctuation Range: ±15%
Membrane Element Operating Limits:
| Maximum Operating Pressure | 600 psi(4.14MPa) |
| Maximum Feed Flow Rate | 17.0m3/h |
| Operating Temperature Range | 45 ℃ |
| Maximum Feed SDI 15 | 5.0 |
| Free Chlorine Tolerance | 0.1mg/L |
| pH Range, Continuous Operation | 3-10 |
| pH Range, Short-Term Cleaning | 1-13 |
| Maximum Element Pressure Drop | 15psi(0.1MPa) |
